GDZS-DT001 / Desktop Service Terminal

The Desktop Service Terminal is a sophisticated device that helps customers improve their paperless business and enhance security protection. lt is equipped with flexible liD document reading and multiple biometric authentication technologies, providing reliable KYC service over the counter. By connecting with different systems, it can assist digital business processes through its dual-side touch displays and other flexible modules. This innovative and user-friendly device can efficiently improve customer service.

This field is required.
This field is required.

NO.

Content

Specification indicators

Standard

Note









1







Motherboard Industrial

Controls

System:Android 11

CPU:RK3568 Quad-core 64bits Cortex-A55(2.0GHz)

GPU:Mali G52 2EE (0.8T arithmetic) 2G RAM+16G Flash ROM









Choose one of  two

System:Android 11

CPU:RK3568 Quad-core 64bits Cortex-A55(2.0GHz)

GPU:Mali G52 2EE (0.8T arithmetic) 4G RAM+32G Flash ROM







2





Power adapter

DC 12v 2.5A



Power Adapter Plug UK PLUG UK Specification

Choose one of  three

Power Adapter Plug UL PLUG US Specifications



Power adapters Plugs EU PLUG European specifications



3

Main Display  (Camera Side)

10. 1 inch display 1280*800 + multi-touch screen



4

Secondary display

10. 1 inch display 1280*800 + multi-touch screen



5

Horn

8  Ω 5 W





6

Portrait Capture Camera

Monocular 2 M

Choose one of  two

Binocular 2 M visible light + 2 M infrared light





7

Documentation High Shooting  Camera

Acquisition area:125mm*90mm; Focus mode:fixed focus; Resolution: 5 M











8





Fingerprint Module

Chip Type: Capacitive Reflective

Acquisition method: press type (support 360-degree rotation acquisition, comparison)

Acquisition area: 10.64mm×14.4mm

Image size: 256*288pixel

Resolution: 508dpi







N/A







Optional











9









Contactless card reader module

Supports ISO/IEC 14443 A, ISO/IEC 14443 B, and holds ISO/IEC 7816 protocols;

Supports NXP Mifare standard;











N/A











Optional

Supports ISO/IEC 14443 A, ISO/IEC 14443 B protocols; Supports ISO/IEC 18092 and ISO/IEC 15693 protocols;   Supports ISO/IEC 7816 protocol;

Supports NXP Mifare standard 、Sony FeliCa standard; Supports VISA and Master card L2 layer interaction;

Pass EMV L1, and EMV L2 authentication (PayPass, PayWave)

10

Contact card reader

Supports ISO/IEC 7816 compliant IC cards;

N/A

Optional

11

Communication interface

1x RJ45 NIC, 1x USB, 1x OTG Support WIFI-2.4G、BT-4. 1



12

Size

278mm*182mm*260mm
